CROMPTON AXjMINSTER LOOMS(Richard Smith & Sons, Kidderminster) MACHINE-MADE TUFTED CARPETS 167 been completed, and that all the colour worsteds have been selectedfrom the stores. They are wound on large bobbins, which are placedon the bank behind the machine. A spool, which resembles a… … Fig. 469.—Tufting Mechanism A, Roller or spool on which the coloured pile threads are wound, turning on a fixed pin B at each end, whoseslanted end is mounted on a finger c. d, The tufting carriage or frame. E, The tufting tubes soldered togetherat F. G, A guide bar to prevent friction against the…
