The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 245
th the tappet lever. When the tappet lever lifts and causes thelifting board to rise, the slotted lever controlling the movements ofthe cylinder also rises; it impinges against the studs on the springlever, and sends the lever along, making the elbow lever drive thelever of the cylinder in the… … Fig. 480.—Tension Weft-trap in Shuttle A, Section of shuttle. B, Cop. c, Weft thread, d, Brass swivelthrough the eye of which the weft thread is led. E, A springpressing the swivel and warp against the pin F. pull the lever along, causing the cylinder to return to the ends of theneedles. As we see,…
