The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 30
Fig. 490.—Section through Above, showing wiresW = Wires. … ig. 497.—Fig. 494 as Woven In this weave there are four shots to each repeat of structure, thus:— Pick I—Single shed. Heald sliaft, 2 up, shafts i and 3 down. Pick 2—Double shed. Heald shaft i up, holding the pile warp upto let the wire in, the stuffer lying under; heald shaft 3, carrying theeven…
