Taggart, William Scott · London : George Routledge & Sons, Ltd. · leaf 84
e the pin atC, but this is prevented by some force acting along the tie rodAC and some force acting along the jib EC. Three forces aretherefore acting on the pin C, to keep it in equilibrium, at anglesindicated by the vertical pull of the weight and the inclinationsof the Jib and tie rod. We now… … 1^.105.
Textile machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
