The theory and practice of modern framed structures : designed for the use of schools, and for engineers in professional practice (1897)

Johnson, J. B. (John Butler), 1850-1902, Bryan, C. W. (Charles Walter), 1863-1927, Turneaure, Frederick Eugene, 1886- · New York : J. Wiley & Sons · leaf 138

An illustration from The theory and practice of modern framed structures : designed for the use of schools, and for engineers in professional practice, 1897, leaf 138 — E THEORY OF BEAMS. 120. Historical Sketch.*—For two hundred and fifty years the true theory of the strength of a beamhas been a much-mooted question amongst physicists, engineers, and mathematicians. Galileo was the first of whom we have any record who undertook to discuss the problem. In hisfamous… … Fig. 164. tension which acted about the base of the beam as a fulcrum. On this theory the moment of resistance of a solid rectangular beam would be where /is the ultimate strength of the material in tension. Robert Hooke first published his famous law of the relation between strain and stress in…

Structural analysis (Engineering) · Bridges · Trusses · Strains and stresses

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
