The theory and practice of modern framed structures : designed for the use of schools, and for engineers in professional practice (1897)

Johnson, J. B. (John Butler), 1850-1902, Bryan, C. W. (Charles Walter), 1863-1927, Turneaure, Frederick Eugene, 1886- · New York : J. Wiley & Sons · leaf 499

An illustration from The theory and practice of modern framed structures : designed for the use of schools, and for engineers in professional practice, 1897, leaf 499 — Fk;. 2. —HiciiiwAY Bridge over VVeiira River, Weiii;, Haden. … Fig. h.—Bridge o\er hie Ri:ine, Cologne, Gicigmanv. Plate XXVIII.

Structural analysis (Engineering) · Bridges · Trusses · Strains and stresses

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
