The theory and practice of modern framed structures : designed for the use of schools, and for engineers in professional practice (1897)

Johnson, J. B. (John Butler), 1850-1902, Bryan, C. W. (Charles Walter), 1863-1927, Turneaure, Frederick Eugene, 1886- · New York : J. Wiley & Sons · leaf 515

An illustration from The theory and practice of modern framed structures : designed for the use of schools, and for engineers in professional practice, 1897, leaf 515 — TOWER BRIDGE, LONDON, Plate XXXU. … Buda-Pesth SiisiKNsioN Hridge. STAND-PIPES AND ELEVATED TANKS. CHAPTER XXVII.STAND-PIPES AND ELEVATED TANKS. 457- Use of Water Towers.—Where high ground is not available for service reservoirsas a part of a city water supply system, they are replaced by the storage of a small quantityof water at a…

Structural analysis (Engineering) · Bridges · Trusses · Strains and stresses

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
