The theory and practice of modern framed structures : designed for the use of schools, and for engineers in professional practice (1897)
Johnson, J. B. (John Butler), 1850-1902, Bryan, C. W. (Charles Walter), 1863-1927, Turneaure, Frederick Eugene, 1886- · New York : J. Wiley & Sons · leaf 519
his is not equal tothe overturning moment, the remainder must be providedfor by anchorage rods extending into the masonry. In Fig. 424, let AB . . . /^represent the anchorages ofthe brackets of a stand-pipe whose centre is O. If weassume the wind to be in the direction ON, then thebrackets A and D… … hd=4000 Thickness of Plates Fig. 423.
