Fig. 91. which fasten It firmly over the centre of the instrument. Theattachment to the side, Fig. 92, is effected by means of a spindlefrom the attached telescope which fits into the hollow axis ofthe central telescope and is secured by means of a clip which MINING SURVEYING. 337 … M. passes through both the axis and spindle. A counterpoise issimilarly attached to the opposite side of the central telescopeto preserve the equilibrium. This latter form of attachment is more com-pact than the former, the principal objection toit being that a correction must be applied toeach…
