ct in the prolongation of AB casts the ADJUSTMENT, USE, AND CARE OF INSTRUMENTS. 115 ray Be directly down the telescope. The angle formed bythe incident and final reflected ray, Rfe, is twice the anglesubtended by the plains of the mirrors Cg ey as was shown inthe case of the sextant. When the rays… … Fig. 25. bar has come into the position Ca, making an angle \(J> withits former position ca, since this is an angle in the circumfer-ence. The mirror SS has also turned through an angle |-0and since it was parallel to the mirror ss in its first position itnow makes an angle y = \ <p with it.…
