totube E, the amplified output of which is obtained in the outputtransformer Ti. Similarly the amphfied currents from Line Epass through the output transformer T2. Now, if the systeminto which transformer Ti, for example, feeds were not s;yTnmetricalwith respect to the points P2, the amplified… … FiG. 148. the impedance of the balancing network equal to that of theline to which it is connected, thus making the potentials of thepoints Pi and P2 independent of the currents m the correspondingoutput coils T2 and T\. This, of course, results in a division ofthe amplified output power, one-half…
