Thermodynamics of the steam-engine and other heat-engines (1907)
Peabody, Cecil H. (Cecil Hobart), 1855-1934 · New York, J. Wiley & sons; [etc., etc.] · leaf 79
o theaxis of zero volume. At the right, the iso-thermal shows a decided break and slopesaway as the volume becomes larger thanthat of the saturated vapor. The isothermalfor 21°. 5 shows similar characteristics, butthe passages from one condition to another are more gradual.The dotted curve is drawn… … Fig. 29a. DENSITY AT HIGH PRESSURE 71 The isothermal for 31.°! is clearly above the critical tempera-ture and does not indicate a liquefaction. The several states of a fluid may be enumerated as 1. Liquid. 2. Saturated vapor, including mixtures of liquid and vapor. 3. Superheated vapor…
Thermodynamics · Steam-engines · Heat-engines
