A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 112

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 112
nt carries the horizontal rod 33 aswell as the vertical rod 32 with it. The rod 32, beingconnected through the shaft 31 to the lever 30, throwsthe end of that lever so that the clutch 27 slidingin it will be forced into contact with the clutch mem-ber 3, and the clutch 27 being keyed sliding on… … Fig. 3. thrown into contact with a clutch member 44 carry-ing gear teeth, and which is continually rotatedthrough a positive drive, by a connection not shown.This rotation is given the feed roll on the run in ofthe carriage and the position of the lugs 4 to thefingers 5 maintained. When the fallers…

Textile fabrics · Textile industry · Textile machinery

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
