A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 219

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 219
slide at its upper end on the rock shaft 13, andguided at its lower end by a fixed rod 29, held at itsfront end in a bracket 30, secured to the front of the 218 frame, and at its rear end said guide rod is supportedin an ear 30 of a bracket 31, fixed to the frame ofthe machine by the bolt 32. This… … FigM the rear of the machine, when the stop motion properoperates and pulls on the link 27, the let off pin willstrike a stud 28^ on a collar 29^, fixed on the rockshaft 13 by the said screw, and the rock shaft will beturned through a sufiicient arc to carry the point 16(see Fig. 3 more…
