A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 234

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 234
end of ashaft 39 to the other end of which is secured an arm40. This arm 40 has connected to it a vertical rod 41.the lower end of which is attached to a lever 42, thislast lever being secured to a shaft 43 which alsocarries a lever 44 \vith a roll 45. On the end ofshaft 43 is a pivoted lever 46… … The lever 46 is controlled by the lower end of lever 9,so that when said lever 9 is actuated by a screw onthe pattern wheel, the lever is moved off the screw 47and the spring on the shaft acts to open the shearsthrough the levers previously explained. Tlir clampinfi or lioJdUig device for the yarn…

Textile fabrics · Textile industry · Textile machinery

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
