A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 257

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 257
h square beater or tension rolls I, and inthe tub we find brass immersion rolls J, supported 256 in brass frame K, for leading the warps through thedye-liquor. The run of the warps through the tub isshown by line L accompanied by arrows. After being dyed, the warps are split out into theiroriginal… … to support pot eye A and small beaters B which drawthe warps C up towards the ceiling from boxes ortrucks placed on the floor. The driving of the ma-chine is so arranged that the beaters on both framesor sections of the machine (receiving and delivery)start, stop and run in unison. Fig. 6 is a…

Textile fabrics · Textile industry · Textile machinery
