A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 93

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 93
Fig. 1. Nut which bears a. C—is Toothedof Rigid Bend D. D—is RigidConical Bendwhich is movedin or out. E—is FlexibleConical Bendwhich rests onD and carriesthe Flats. By turning theIndex Nuts Aand the ToothedNuts C one wayor the other, theymove the RigidBend D in orout, and thereby raise or lower… … 93 on Index Nuts A represents the 1000th part of aninch, and by turning the Nuts the distance of a di-vision in one direction or the other, the Flats arecorrespondingly raised or lowered to this extent. The setting cannot be tampered with after the KeyB has been used to tighten the Toothed Nuts C.…

Textile fabrics · Textile industry · Textile machinery
