A treatise on architecture and building construction (1899)
International Correspondence Schools · Scranton, The Colliery engineer co. · leaf 24
Fig. 11. A common form of copper-lined wooden tub is shownin Fig. 11, The bath empties through the l-|-inch waste §16 PLUMBING AND GAS-FITTING. 13 pipe «, through the 1^-inch half-S trap b, into the drainagesystem. A 1^-inch lead overflow pipe c connects the copperoverflow pipe horn d to the trap.… … Pig. 12. over the top of the standing tube a, and when the tub is tobe emptied, the tube is pulled upwards, thus uncovering theperforations at the bottom of the inner tube <r, as shown.The outer tube is provided with a rubber ring d, which makesa water-tight joint with the seat when it is…
