Fig. 127. 158. To an Inaccessible Line. The shortest distance, C D, froma given point, C, to an inaccessiblestraight line A B, is required. FromC let fall a perpendicular to A B, bythe method of Art 119. Then set astake at any point, E, on the line A C ;set a second, F, at the intersection ofE B… … Measure C H and H F.CH + HF Then is C D = CH-HF or CD = CH. CH-HF or CD = CHX CF 2CH-CF OBSTACLES TO MEASUREMENT IN CHAIN-SURVEYING. 97 When two lines (as A B, Fig. 128.
