en them. (The 686 Steam Engineering sectional view is from another installation and only showsfour tnbes.) Baffle plates^, C^ are arranged above the spacebetween each pair of tubes. The spaces surrounding theconduits^ and^ under certain conditions^ even the conduitsthemselves^ are filled with water… … Fig. 295 the water^ with^ occasionally^ a further escape from thebottom openings. A large baffle plate in the upper steam<5pace serves for a perfect separation of entrained moisturefrom the steam. The steam enters by the pipe shown at theleft hand of the side elevation^ passes to the interior of…
