d subdivision of the stream being securedby baffle plates, and the tubes themselves. In cases of veryhigh pressure the air may pass through the tubes, for struc-tural reasons. A properly designed intercooler havingsufficient cooling area for the volume of air may reduce thetemperature of the air… … Fig. 347 INGERSOLL-SERGEANT CLASS A-2 THREE STAGE STRAIGHT LINESTEAM DRIVEN AIR COMPRESSOR ^ ^ Air Compression 819 reaches a temperature about the same as that attained inthe first cylinder. In two stage machines this air will bedischarged directly to the receiver without further cooling,unless…
