Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise .. (1916)

Swingle, Calvin F. (Calvin Franklin), b. 1846 · Chicago, F.J. Drake & company · leaf 390

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise .., 1916, leaf 390 — Fig. 120 circle. At this point we can study the effect of inside lap,because if the valve has no inside lap, release on the crankend will begin almost at the same moment that compres-sion takes place at the head end, but by adding inside lap,compression can be caused to take place earlier and… … Fig. 121 The next event is admission at the head end of thecylinder, Fig. 121. The crank has now arrived at 180°,having completed one-half of a revolution; the piston isat the end of the stroke, and the eccentric is at 120° onthe return path. Fig. 122 serves to better illustrate therelative…

Steam engineering · Electrical engineering · Steam-turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
