een them. (The 686 Steam Engineering sectional view is from another installation and only showsfour tubes.) Baffle plates, C, are arranged above the spacebetween each pair of tubes. The spaces surrounding theconduits, and, under certain conditions, even the conduitsthemselves, are filled with water… … Fig. 295 the water, with, occasionally, a further escape from thebottom openings. A large baffle plate in the upper steam<space serves for a perfect separation of entrained moisturefrom the steam. The steam enters by the pipe shown at theleft hand of the side elevation, passes to the interior of…
