its main shaft through a small belt running 1094 Steam Engineering around the armature shaft. (See Fig. 474.) By meansof magnetic clutches and bevel gears^ a pinion shaft isrotated^ which moves the rack and the rocker arm and soshifts the brushes on the commutator to maintain a sparkof about % in.…
