Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 411
and can easily be disconnected in case it is desired to workthe valves by hand, as in warming up the engine prepar-atory to starting np. … C rm:\ \/vfijyc Plate W TIT Fig. 137 Referring to Fig. 136, A is the wrist plate, B and C arethe dash pot rods, D, Y) the dash pots and H E the hookrod. G and G represent the governor rods, and the figures1, 2, 3 and 4 indicate the valve rods with turn buckles forchanging their lengths. ^ Valves…
