Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 619
Fig. 251section of westinghouse double flow turbin«* wo steam Engineering … Fig. 252 WESTINGHOUSE DOUBLE FLOW LOW-PRESSURE TURBINE Sectional Elevation Fig. 251 shows the machine as adapted for using steamof high initial pressure, in fact an impulse turbine, in whichthe steam admitted first to the nozzle block, is expanded Westinghotise-Parsons Steam Turbine 607 in nozzles…
