Twentieth century hand-book for steam engineers and electricians, with questions and answers .. (1905)

Swingle, C. F. [from old catalog], Horstmann, Henry Charles, 1858- [from old catalog], Tousley, Victor Hugo, 1875- [from old catalog] · Chicago, F. J. Drake & co. · leaf 516

An illustration from Twentieth century hand-book for steam engineers and electricians, with questions and answers .., 1905, leaf 516
cted in shunt with the right field of the generator. ELECTRICITY FOR ENGINEERS 97 Facing the rheostat with the right binding posts at thebottom, the contact on the right side or No. I givesopen circuit and throws the rheostat out of use. PointNo. 2 gives a resistance of 44 to 46 ohms and PointNo. 3… … FIGURE 57. other sizes of generators, the adjustment of the rheo-stat must be made to suit the conditions. When the rheostat is in use, the sparks at the com-mutator will be somewhat larger than normal, but willnot be detrimental. The controller magnet (see Fig. 58) is to be fastenedsecurely by…

Steam engineering · Electrical engineering · Steam turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
