Types and details of bridge construction (1904)

Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 146

An illustration from Types and details of bridge construction, 1904, leaf 146 — Woodsville Bridge Approach Girder Abutment Bearings,B. & M. R. R. trestle columns, and the ends of adjacent girders are webspliced together through double cover plates riveted to thefixed girders and bolted through slotted holes for the expansionends. Woodsville. — The double-deck Woodsville…

Bridges

Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
