ble-traclc 25-ft. spans of the Delaware, Lackawanna and West-ern Railroad, at Newark, N. J., have fixed and expansion connec-tions on opposite sides of the transverse bents. The fixed endgirders are field-riveted through their end web-stiffener angles tothe webs of the transverse girders and to… … Newark Bridge, D. L. & W. R. R. Each pocket is made with a pair of vertical longitudinal gussetplates having their lower ends connected by a horizontaldiaphragm built up of a pair of 6 x 6 x |-in. angles and a |-in.plate. This forms a bearing nearly 2 ft. long for the bottomflange of the…
