other bearings for the girders being fixed both on the columnsand on the abutments. The girders are of simple, ordinary construction, with full-length plates and angles in the T-shaped flanges so that splices 294 BklDGE CONSTRUCTION … •i„9,£l LUOOij TRACK ELEVATIONS 295 are required only for the web plates, which are made in as longpieces as practicable. At the abutments the upper corners ofthe girders are rounded to a radius of 26J in., elsewhere theyare square. Not more than three sections of web plates areused in any span,…
