Types and details of bridge construction (1904)
Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 366
ft. 2h in. long on centers are sus-pended by pairs of eyebars, and complete the three-section 105-ft. 3^-in. spans. There are four main lines of girders 17 ft. 4 in.apart, which are connected by floorbeams 15 ft. o^ in. apart,and by two sets of lateral rods and sway-bracing, one set betweenthe… … y^° ° - °l J : i/y,]S. —>^ 35© BRIDGE CONSTRUCTION has a vertical curve and grade down to each abutment. Thereis one 46-ft. driveway and two 12-ft. sidewalks partly supportedon the 9-ft. cantilever extensions of the floorbeams. The rollersare of steel; all other parts of the superstructure are…Bridges
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
