mensioned and detailed as indicated in the ele-vation, and the maximum flange section consists of two 8x8X H-in. angles, two 21 x S-in. web plates, and five 20 x IJj-in.cover plates. The cover plates are not spliced, but the flangeangles are each spliced in two places, and the vertical flangeplates… … RAILROAD PLATE GIRDER SPANS 83 angles are cut 28 in. short at each end, and their ends abutagainst the horizontal upper ends of the end web-stiffener anglesof the same dimensions which are curved to fit the uppercorners of the girders with a 28-in. radius, thus avoiding thedifficulty of bending…
