Union textile fabrication, with numerous original diagrams, sectional drawings, and photographic re-productions of spun and woven specimens in the text (1920)
Beaumont, Roberts, 1862-1924 · London, New York, Sir I. Pitman · leaf 345
of the woven piece. That is to say, they allow of the picks, sketched in black and in tinted grey, being arranged and grouped with the same freedom as in the production of two-ply manufactures. Referring to the sectional drawings, they represent the orders of the intersections of picks 1 to 6 in… … A B C D E F G H A B C D EFGH A B C D E FGH FIG. 196 FlG. 195 FIG. 194 a cassimere twilled structure between two eight-end weft sateen surfaces ; in Fig. 195A, a 4-and-4 twill fabric between two eight-end weft twill cloths ; and, in Fig. 196A a plain- woven structure betwixt an eight-end weft twill…
Textile fabrics
Internet Archive · University of California Libraries · Public domain (published before 1931). Free to use for anything.
