Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 115

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 115 — ; and short guides are providedat the connections of the levers H and C and tlie valve stems. An inspection of Fig. 110 will show that the link has a peculiar move-ment, composed of the horizontal and vertical throws of the eccentric. … The link is restrained from rising by the trunnions, and the horizontalthrow of the eccentric draws off the lap of the valve, while the verticalthrow tips the top of the link alternately to and from the C3dinder, asthe eccentric center rises or falls in its revolution, the upward throw tip- THE…

Steam-engines
