Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 123
t the valve, first slacken the nuts B just enough to allow thering F to expand slightly, then to expand it slacken the bolts G Gand run the set screws H in until the required expansion is accomplished.If the first trial is not sufficient, continue until the proper adjustment isreached. If it is too… … THE FITCHBURG ENGINE 113 starting bar. After the adjustment is completed tighten the nuts B andthen see that the screws and bolts G and H are tight and evenly set up all
Steam-engines
