Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 124

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 124 — = o V J J o - - / r - \ … Sectional View of Packing Ringi

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
