Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 14
FIG. 1. is the exhaust port; V is the valve; a a are the steam edges of the valve,and h h the exhaust edges; c c are the exhaust edges, and d d the steamedges, of the cylinder port. Above the valve are shown the valve circles, one for each end. Theeccentric position is at e when the crank is at c,…
Steam-engines
