Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 169
both types of valve. Fig. 161 shows the position of the wrist plate when the engine is onthe center and the eccentric is advanced to give the steam valves properlead. The adjustment of the dashpot rods is obtained in the manner de-scribed in the preceding section of this chapter. Fig. 162 shows the… … XVIITHE WRIGHT STEAM ENGINE Wright engines were designed and built by the late William Wrightand many of them are still in use throughout the country. During themany years of his activity in the engine field, Mr. Wright designed a num-ber of different types of valve and valve motion for his steam…
Steam-engines
