Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 172
s the steel toe & in the yoke is also indicated. When the wrist plate is in the position indicated in Fig. 167, the othervalve-rod pins are in the positions shown, and when the wrist pin is at cat one extreme of its throw, the other valve-rod pins are at c^, c^ c^ and c*^respectively. By the… … FIG. 165. 162 VALVE SETTING one of the shafts. The sj)lined spindles / / pass through the hollow rockshafts and valve cranks as shown^ and on one end is a nut g which canbe adjusted to lengthen or shorten the spindles. At h is shown the keywhich is set diagonally across the end of the spindle and…
Steam-engines
