Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 25
-> … FIG. 11. minutes, which is equal to 47.9 per cent, of stroke. Eefer again to Fig.15, in which K C A is the angle of admission, either angle LCD, K C L,or A C P being the angular advance, and R P the linear advance equalingthe lap. If the lap were 30 per cent, of the valve travel, the angular…
Steam-engines
