Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 30
riG. 17. … tion 0—B, and compression will take place earlier, at 0—Z), the effectbeing exactly opposite for a decrease of the inside lap. In Fig, 18 is shown the effect of altering the angular advance of theeccentric. It will be seen that if the angle of advance is increased, asat a, all the events of the…
Steam-engines
