Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 51

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 51 — M … FIG. 37. of admission of steam through the valve port K to the cylinder port ais governed by the action of the cut-off valve. In this case, where the eccentrics are set as they are, the cut-off valvemoves across the main valve port K before the latter valve has cut off,

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
