Vaux, Calvert, 1824-1895 · New York, Harper & brothers · leaf 110
ca. G and H are illustrations showing the foot ofverge-board and construction of gutter in a roof withcurved eaves. The mode of continuing the gutter tothe rain-water head applies also to any roof in whichthe gutter is cut out of the rafters. Some designs forheads are shown at I and K. Chimneys are…
Architecture, Domestic
