The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)

Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 144

An illustration from The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses, 1903, leaf 144 — t length. The watch-maker should buy the one which fits his lathe, as then histapers and push spindles will be all alike, or should be, andhe thus saves the duplication of tools. Do not buy an imita-tion tailstock unless you have an imitation lathe, for thereasons just given. Two spindles should be… … Fig. 118. The Clement Swing Tailstock. Fig. 118 shows the Clement swing tailstock, which is thelatest development of the tailstock, as a tool carrier forwatchmakers. It is made to fit any make of lathe and con-sists of a base pivoted on a shoe, which fits the lathe bed.The rear end of the base is…

Clocks and watches · Lathes

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
