The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)

Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 207

An illustration from The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses, 1903, leaf 207 — of thesecollars on the arbor and bolt them up firmly. Set the indexpin at zero in the lathe head. Place a drill in the pivot pol-isher and drill a hole through the two collars half waybetween the center and circumference. Turn the index to 2o6 THE AMERICAN LATHE. 1S0 and repeat the operation; do…

Clocks and watches · Lathes

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
