The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)

Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 225

An illustration from The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses, 1903, leaf 225 — 770.Z06 tic. 2t i fr( Br£)\. °*\. 0» ./ … Fig. 205 to 209 Details of worm, worm wheel and index for dividinghead to attach to a watchmakers lathe. about il/2 inches long that will fit the T slot in the lathe bed,as shown by dotted line in Fig. 203; then drill the hole B,and with the dividers at this point draw the arcs that makethe sides…

Clocks and watches · Lathes

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
