The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)
Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 49
g construction of parts. Figs. 31 and 32 show a lathe that is having a considera-ble sale in America, although it is made in Europe. Thelathe is of the Moseley pattern (i. e., it has center guides),and the headstock is made one-half inch longer, to giveroom on the spindle for the ball bearings. H… … THE AMERICAN LATHE. 49 bearing of the headstock is simply enlarged and grooved atits inner end2 to make the ball seat; also that the ball raceis screwed on the spindle, instead of sliding upon it, so thatit is adjusted by turning the race, whereas in the Dale therace slides on the spindle and is…
Clocks and watches · Lathes
