Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)
American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 130
nchesstroke. It requires a considerable amount of skill in the setting ofthese motions, but when they are set they give fair results. Yetthe time spent in setting is not balanced by these results. Whencompared with the motion in Fig. 68, it is seen that one is placedinside of the loom and out of… … IS O WEAVING. 105 The cams for the roll top motion are fixed on an auxiliary shaftand the shaft receives motion from the pick cam shaft. The samerule applies when calculating the gears that drive the cams, except
