Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)
American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 30
olutions will equal 1,000 yards. The number of teethin the cut gear A corresponds to the number of yards in a cut;therefore, if this gear contains 50 teeth, the number of yards ineach cut will be 50. Three teeth oil the 48 gear equal one yard:48 -^ 16 := 3, the motion having been reduced three… … WARP PREPARATION. 19 or the number of yards in the whole wrap. By the substitutingof the 64 gear below the cut gear the ratio will be equal to 4 to 1.Thus the number of teeth in the gear B will be 4 times greaterthan the number of cuts in the leese. Example. We require 1,000 yards of j^arn on the…
Weaving
