Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)
American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 336
e, for it sometimes happens that one hook is lifted while theother is pressed back by the cylinder, so that the same thread willnot be lifted for the next pick. The bottom x)f the hook is made in the form of a capital let-ter Y. The reason for this is that it saves a considerable amount 300… … bottom of the hook passes. Fig, 23 shows the position occupiedby the hooks when one hook is lifted and the other hook (whichpasses through the same needle) is pressed off. The dotted linesshow the original positions of the hooks. 301 24 JACQUARD MACHINES In addition to the added friction on the…
Weaving
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
